Large Build Volume for Copper Printing
Large parts formed in one piece
Small Light Spots
40 μm spot diameter
Multi-light Efficient Printing
2 laser with bi-directional powder spreading
Permanent Filtration System
Uninterrupted continuous production
Product Introduction
M350G, with a build volume of 350*350*500mm, boasts a robust modular design and can be equipped with one or two green fiber lasers, available in 500W, 700W, or 1000W. The system enables efficient printing of materials like copper copper alloys, and precious metals, which are difficult or impossible to process with infrared lasers.
The machine's modular platform gives flexibility to reproducible production and easy maintenance. Its open-source system supports extensive parameter customization and a wide range of materials. The system is open to integrate seamlessly with upstream and downstream software.
Incredible Printing Performance with Cooper and Copper Alloys
Green laser enables additive manufacturing of highly reflective materials to print more effectively and efficiently. It delivers a high absorption rate and generates less spatter during printing. Finer details can be achieved due to the small spot size of the green laser. The performance of the printed cooper and its alloy parts is enhanced.
Density≥99.8%
Electrical Conductivity≈101%IACS
Thermal Conductivity≈390W/(m·k)
Min. Wall Thickness 0.08mm
Note: Pure copper heat treated. The test parameter can vary according to factors like printing parameters, and material used.
Fast Printing Speed in Copper and Copper Alloys
15-55cm3/h (Green laser) vs
1.7mm3/h (Infrared light)
Note: Typical printing speed of 1kw NIR laser
Efficient Speed and Fine Details
With a dual laser system, bidirectional powder coating, and equipped with large layer thickness printing parameters, printing can be more efficient. With a small spot size down to 40µm, fine details can be realized.
Software
M350G is equipped with self-developed ADR BP and ADR Print software.
Supports simultaneous printing of multiple workpieces with different layer thicknesses
Allows users to independently set process parameters for different areas of the model
Intelligent data monitoring for real-time detection of oxygen levels, pressure, and temperature, along with real-time alerts. The system will automatically stop the machine in case of any failure, ensuring safe and reliable printing.
XH-M350G
Data Download
| Model | XH-M350G |
| Build Volume | 350*350*500mm ① |
| Laser Source | Continuous single-mode green fiber laser, wavelength 532nm, optional with 500W, 700W, 1000W |
| Spot Diameter | 40-60μm |
| Focusing System | F-theta lenses focusing |
| Printing Speed | 10-30 cm³/h single laser, 20-55 cm³/h double laser |
| Layer Thickness | 20-120μm |
| Powder Feeding Method | Top powder feeding |
| Protective Gas | Nitrogen, argon |
| Power Supply | AC 380V, 50/60Hz, voltage fluctuation ≤10%, three-phase five-wire system, 32A |
| Machine Dimensions | 3050*1750*2850mm |
| Machine Weight | Approx. 3.9T |
| Compatible Materials | Pure copper, copper alloys, refractory metals, composite materials (Cu-based diamond composite, Cu-based graphene composite ,etc.), other conventional metals |
| Note: (1) The height of the build plate is not included |
